Hermetic Compressor Cutaway
Model Number: 373-110
Hands-on HVAC training aid that reveals compressor internal components, design, and operating principles.
Overview
DAC Worldwide’s Hermetic Compressor Cutaway (373-110) is an expertly-sectioned example of a common fractional-horsepower refrigeration compressor, which facilitates and supports practical training in compressor design, operating principles, and maintenance. Both the steel shell and the compressor itself are cut away, allowing for full visibility of the compressor’s operating components.
A full cutaway view of the valve body and seat area exposes the compressor’s complete internal design. Cutaway surfaces are enhanced through painting, making the geometry of all components more clear. Multiple cutaways unveil all internal components, which enhances classroom training in HVAC system design, maintenance, troubleshooting, and preventive/predictive maintenance.
The full-size, fully-detailed example gives learners a first-hand view into a component that is found in various applications worldwide. This professionally-crafted, yet-economical component sample will enhance HVAC training activities in both the industrial and the educational setting.
Features
- Sectioned fractional-horsepower, single-cylinder hermetic refrigeration compressor
- Cutaway of both exterior casing and compressor casting
- Full visibility of internal operating components
- Full cutaway view of the valve body and seat area
- Precision-painted cutaway surfaces for improved definition and 3-dimensionality
- Components retained and fully visible for visual learning
- Individually mounted cutaway areas removable from the baseplate
- 10-gauge formed-steel powder-coated baseplate
- Provision for mounting on DAC storage, display, bench, and workstation products
- High-endurance urethane-coated surfaces for durability
- Color-coded component parts to enhance learning
- Crated for shipment via motor freight
Specifications
- Model: 373-110
- Product dimensions (L x W x H): 12 in x 13.75 in x 9.25 in (304 x 349 x 234 mm)
- Shipping dimensions (L x W x H): 21 in x 15 in x 13 in (534 x 381 x 330 mm)
- Construction: 10-gauge formed-steel powder-coated baseplate
- Compressor type: Fractional HP, single-cylinder, hermetic refrigeration compressor
Topics Covered
- Compressor design
- Compressor operating principles
- Compressor maintenance
- HVAC system design
- HVAC troubleshooting
- Preventive maintenance
- Predictive maintenance
Hands-On Training
The trainer gives learners a first-hand view of a common fractional-horsepower refrigeration compressor through carefully planned cutaway areas that expose the complete internal components and valve body/seat area. Components are retained and visible, cutaway surfaces are precision painted for clarity, and the individually mounted sections can be removed from the baseplate for convenient classroom use.
Curriculum
This training aid supports instructor-led training and independent student self-discovery in vocational and academic air conditioning and refrigeration programs. Its full-size, fully detailed construction helps learners study compressor design, operating principles, maintenance, troubleshooting, and preventive/predictive maintenance.
Options & Accessories
- Recommended 373-002 Tabletop Support Frame
- 902 – Electromechnical Workstation
- 903 – Electromechanical Workstation, Extended
Items Included
- Hermetic compressor cutaway training sample
- Sectioned fractional HP, single-cylinder hermetic refrigeration compressor with cutaway exterior casing and compressor casting
- 10-gauge formed-steel powder-coated baseplate
- Crating for shipment via motor freight
